Professional power amplifier

The XA2-16 is a 16×220W Class D digital amplifier. High current and low load output, can promote AC load as low as 1 ohm. It can precisely control the moving tongue movement of moving coil speaker, so it has high fidelity reduction degree to audio.
System parameters:
Output power: (AC load)
16 × 220W RMS (4 ohms) continuous power
16 × 350W RMS (2 ohms) continuous power
16 × 450W RMS (1 ohm) continuous power
Harmonic distortion: <10% 1KHz (less than 2 ohm load)
Frequency response: 10Hz ~ 30KHz (+ 1 / -1dB)
SNR: 111dB
DNR: 115dB
Power: 170V ~ 250V 50Hz
Power consumption: 5000W
Size (H x W x D): 230 × 430 × 385mm
Weight: 50KG

1,16 channel current type D class pure power amplifier;
2,16 group 36V high current (Class A power supply);
3, Class D integrated power amplifier with 98% efficiency
4, up to 5-10 amps per channel
5, can be as low as 1 euro AC load;
(毎 sound channel 175W / 4 Europe -450W / 1 Europe)
6, thick low-frequency;
7, clean, transparent, delicate high-frequency;
8, on the full-range loudspeaker live tongue movement, retractable and free, the slightest completed;
9, a strong current to promote the ultra-low dynamic control unit, lifting weight, low-frequency scene accurate reduction;
10, the whole net weight: 50 kg;


系统参数:

输出功率:   (交流负载)
16×220W   RMS (4欧)    连续功率
16×350W   RMS (2欧)    连续功率
16×450W   RMS (1欧)    连续功率
  谐波失真:              <10%  1KHz(低于2欧负载时)
  频率响应:              10Hz~30KHz(+1/-1dB)
    SNR:                      111dB
  DNR:                     115dB
  电源:                     170V~250V  50Hz
  功耗:                     5000W
  尺寸(高x宽x深):   230×430×385mm
  重量:                     50KG

1,16声道电流型D类纯后级功放;
2,16组36V大电流(甲类电源);
3,效率98%的D类集成功放;
4,每声道高达5-10安培电流;
5,可低至1欧交流负载;
(毎声道175W/4欧-450W/1欧)
6,厚实的中低频;
7,干净,通透,细腻的中高频;
8,对全频扬声器的活舌运动,收放自如,毫厘毕现;
9,强大的电流推动对超低单元的动态控制,举重若轻,低频场景精准还原;
10,整机净重:50公斤;
