5-inch four-way speaker

The private customized CI-581 is a 1-inch horn treble, 28-core silk film mid-high pitch drive unit, 5-inch carbon fiber compound basin bass 8 inch carbon fiber compound basin bass, comes with the box, into the wall installation. Small home and business applications space demand power 250W.Private custom CI-581, quarter frequency design, used in a large number of cases when the main speaker is used, the tone is rich and sweet, high frequency transmission can be externally controlled and regulated, the sound pressure is dynamic and the frequency range is wide. the tone color can be modified according to the space application and environment with high tun ability, It's got a body, it's got a body frequency division, into the wall installation.

  System parameters:
  Speaker Type:   Embedded、Hidden
  Treble converter: 1 inch horn treble
  Treble converter: 28-core wire super high tone
  Alto converter: 5-inch carbon fiber composite bass
  Low-frequency inverter: 8-inch carbon fiber composite bass
  Rated power: 200W
  Frequency response: 65Hz-20KHz
  Rated impedance: 4 ohms
  Sensitivity: 95dB
  Connector Type: red and black terminal
  Available surface: Black brushed aluminum panel
  Pure aluminum brushed panel size: 315 width × 715 high × 10 deep mm
  Installation opening size (box size): 300 width × 700 height × 120 depth mm

系统参数：

  扬声器类型：嵌入式、隐藏式
  高音变频器： 1寸号角高音
  高音变频器： 28芯丝膜超高音
  中音变频器： 5寸碳纤维复合盆中低音
  低频变频器： 8寸碳纤维复合盆低音
  额定功率：   200W
  频率响应： 65Hz-20KHz
  额定阻抗： 4欧
  灵敏度： 95dB
  连接器类型：红黑接线柱
  可用表面：黑色拉丝铝合金面板
  纯铝拉丝面板尺寸： 315宽×715高×10深mm
  安装开口尺寸（箱体尺寸）: 300宽×700高×120深mm
