Bar full frequency speaker

(10+2 units)

The box body is formed as a whole, without wire assembly and connection. The thickness of the cast aluminum box body is ≤ 5mm, and the iron mesh adopts a 1.2 aperture ultra-thin mesh, which has strong sound penetration and plays a dustproof and waterproof protection role. Convenient installation with adjustable coverage; 10+2 unit structure, dual frequency division design, high pitched using neodymium magnetic wire film compression horn, can carry large dynamic sound reinforcement use, high pitched delicate and transparent; The bass adopts a combination design of 10 units of 3-inch full frequency speakers, with a combination of natural magnets and neodymium magnets. The rubber bubble edge wool fiber paper basin has strong magnetic power, and the sound is soft and clean, with a wide frequency and deep potential. The compact size is suitable for various modern multifunctional halls, conference rooms, clean bars, urban exhibition halls, and other spaces.

Parameter Description

Output power: 450W
Response frequency: 90Hz-20KHz
Impedance:   6.8 Ω
Diffusion angle:   120 ° x120 °
Sensitivity: 101dB
Dimensions (W * H * D) 85 W * 1485 H * 105 D MM
Net weight:   8Kg
Installation method: wall mounted

输出功率： 450W
响应频率： 90Hz-20KHz
阻抗：    6.8Ω
扩散角度： 120°x120°
灵敏度： 101dB
尺寸（宽*高*深） 85宽*1485高*105深MM
净重：     8Kg
安装方式：    壁挂
