8 inch 6-way speaker

Private custom CI-458, quarter frequency design, suitable for large space use, sound color can be external control adjustment, sound pressure dynamic large, wide frequency range, according to space applications and environment tone color modification, high adjustable, built-in box body, built-in frequency division, into the wall installation.

                                           System parameters:
                                           Speaker Type:                                                                   Embedded, Hidden
                                            Treble converter:                                                             1 inch horn treble
                                            Treble converter:                                                             2X28-core wire super high tone
                                           Alto Inverter:                                                                    4X5-inch carbon fiber composite midsole
                                            Low frequency converter:                                               4X8-inch carbon fiber composite bass
                                            Rated power:                                                                   500W
                                            Frequency response:                                                       45Hz-20KHz
                                            Rated impedance:                                                           4 ohms
                                            Sensitivity:                                                                       96dB
                                            Connector Type:                                                              red and black terminal
                                            Surface treatment:                                                           Black brushed aluminum panels
                                            Pure aluminum brushed panel size:                                315 wide × 2000 high × 10 deep mm
                                            Installation opening size:                                                300 wide × 1990 high × 120 deep mm
